Waterford Precision Cycles

Shop Equipment

• (1996) Shuz Tung Bicycle Tube Miter Mill (Seat, Top & Down Tube w/Water Bottle Drill), Model HT-10152, s/n 610-00672, (3) Horizontal Heads, (1) Vertical Head, Hydraulic Clamping, Coolant, Operator Control Panel
• (1988) Bike Machinery (Italy) Horizontal Top/Down/Seat Tube Mill, s/n 110.101 Schwinn Tag: 2176, (2) Horizontal Heads, Pneumatic Clamping, Coolant, Operator Foot Pedal
• Bike Machinery (Italy) Horizontal Top/Down Seat Tube Mill, s/n 110.123, Schwinn Tag: 2692, (2) Horizontal Heads, Pneumatic Clamping, Coolant, Operator Foot Pedal
• (1997) Schuz Tung Bicycle Frame Alignment Table, Model HT-50-21, s/n 610-000853, Hydraulic Bottom Bracket Clamping, Foot Pedal, Head Tube Blocks, 44 ID Head Tube, 100/73 & 68mm Bottom Brackets, 196/148/130/170/120/135mm Rear Axle Spacing
• Geo. T. Schmidt GTS/Hi-Duty Bottom Bracket Serial Number Stamping Machine, Model 175-3, s/n 10524, Code 85, Hydraulic Up-Acting Type, Manual Clamping Jig, 2 Button Safety Operator Pedestal, 68/73mm Bottom Bracket Capacity
• Geo. T. Schmidt GTS Pneumatic Bend/Bump/Dimpling Press, s/n 3842, Schwinn Tag: 542, Operator Bottom Cycle, Tooling Separate
• Rear Triangle Tacking Jig, Bottom Bracket Clamp, (4) Rear Drop Out Width Fixtures (120mm/130mm/135mm Through Axle Jig), Mounted On Rolling Park Tool PR5-3 Stand
• (Circa 1993) Letch Frame Welding Jig, Fully Adjustable, Manual Clamping, Tilting Rolling Frame, 700mm Front/Center & 680mm Seat Mast Max Capacity
• Anvil Fork Welding Jig for 1” & 1 1/8” Steer Tube, No Stand
• (1982) Frame Tacking Jig, Schwinn Tag: 1904, Fully Adjustable, Manual Clamping On Multi-Angle Floor Mounted, 750mm Front/Center & 760mm Seat Mast Max, 450mm Chain Stay Length, Main Jig For Paramount & Waterfonds, Approx. 25,000 In Total
• Delta/Paramount Drill Press, Water Bottle Drill, s/n 39-9534, ¾ HP, Reynolds Drill Head, Manual Tube Clamp, Belt Cover I’s Custom Painted by Rodger Kruger, “Paramount”-Rare!
• Delta Drill Press V-Block w/Stop Drill, s/n 77-8857, Schwinn Tag: 342, ¾ HP, Stock Clamp, “V” Jig, Adjustable Stop
• Wilton Pedestal Type 2” Abrasive Belt Grinder, 1 HP, Adjustable Stage, Operator Foot Pedal
• (Circa 1993) Long Race Fork Blade Bender, T-Slot Table, Table Mounted but currently not mounted
• Bridgeport J-Head Vertical Mill, s/n 38374, 9” x 42” T-Slot Table, Adjustable Speed Head, 80-2720 RPM Reversible, 1 HP, 3 Phase Plug, Lo Speed Only
• Bridgeport J-Head Vertical Mill, s/n 87007, 9” x 36” T-Slot Table, Adjustable Speed Head, 80-2720 RPM Reversible, 1 HP, 3 Phase Plus, Hi Speed Only, Down Feed No Longer Works
• (1986) Eisele 90° Cold Tube Saw, Model VMS-1, s/n 81962, 1.2 HP, 3 Phase Plug, “V” Type Manual Tube Clamp w/Stop, Pedestal Mounted
• Farr Frame Works “Get A Grip” Tube Butt Gauge, Dial Indicator Type
• Kenco/Teledyne 5 Ton Seat Tube Top Slotter Press, Model 054-105-200, s/n 80-732, Schwinn Tag: 2173, Operator Foot Pedal, Pedestal Mounted
• Bridgeport “J” Head Vertical Mill, s/n 142797, 9” x 42” T-Slot Table, Adjustable Speed Head, 80-2720 RPM Reversible, 1 HP, 3 Phase Plug, Auto Feed No Longer Works
• (1997) Shuz Tung Semi-Automatic Bicycle Tube Miter Saw, Model HT-10-01, s/n 312-322, Pneumatic Clamping w/Stop, Coolant System, Operator Foot Pedal, 3 HP, 3 Phase Plug
• Nichols Horizontal Mill, s/n 6-J-2786, 6 ¾” x 30” T-Slot Table, ¾ HP, 3 Phase Plug
• (Circa 1989) Willis Little Bear Radial Arm Drill, Model RD-750, Variable Speed, 88-1500 RPM, 2 HP, 3 Phase Plus, 90° T-Slot Table, Coolant System, #2 Morise Taper
• Jet Custom 10” Tube Type Drill Press, Model JDP-10, s/n 7070089, Metal Pedestal Mounted
• Black & Decker 8” Pedestal Type Double End Grinder, Model 4325, s/n 80170292, 9.75 Amp, Single Phase Plug
• Milwaukee 14” Abrasive Cut Off Saw, Model 6176-20, s/n 968B900, 15 Amp, Single Phase, 3950 RPM
• (1996) Clausing/Startrite Tube Type Miter Saw, Model SC-350-D, s/n 153444, 70 Amp, 3 Phase Plug, Manual Tube Clamp
• LeBlond Regal Engine Lathe, s/n 8C-4172, Approx. 16” Swing x 30” Between Centers Capacity, 10” 3-Jaw Chuck, 2 Position Tool Post, Tail Stock, 30-1200 RPM, Owner states ways need to be redone
• Delta 17” Drill Press, Model 17-900, s/n R8747, Schwinn Tag: 2958, ¾ HP, 1 Phase Plug, Adjustable Stage
• Fork Alignment Table, Schwinn Tag: 1179, Pneumatic Type, 1” & 1 1/8” Steer Tube, Cold Setting Tools, Variable Rake Gauges
• Marathon Tube Type Cold Miter Saw, 2 Speed, Manual Clamping w/Stop, Needs New Clamp Bushings
• Grizzly Variable Speed Tilting Head Bridge Mill, Model 83ZYT-350, ¾ HP, 6000 RPM, 3 ½” x 15” T-Slot Table, Tooling, ½”-3/4” Bridge Tube Capacity
• Rockwell Bench Type Bridge Mill, Model 15-081, s/n 1774534, Wood Table Mounted, Road  & ½” Round Thru Hole Capacity
• Bridgeport J-Head Vertical Mill, s/n 126032, 9” x 42” T-Slot Table, Adjustable Speed Head, 80-2720 RPM Reversible, 1 HP, 3 Phase Plug, Mitutoyo X & Y DRO
• Econoline 2 Hole Sand Blaster, 47”W x 47”D Deck, Flip Up Cabinet, Reclamation/Dust System, Operator Foot Pedal, Interior Light
• Wilton Centerless Grinder, Model 4730, s/n 300057, Analog Controls
• Chainstay Miter Jig, (2) Seat Stay Mitering Jigs (1-Road/1-Mtn Bike), 1”-1 1/8” & 44mm Head Tube Ream/Facer
• Bridgeport J-Head Vertical Mill, s/n 48792, Schwinn Tag: 1422, 9” x 32” T-Slot Table, Adjustable Speed Head, 80-2720 RPM Reversible, 1 HP, 3 Phase Plug, Auto Down Feed No Longer Works
• Milwaukee 14” Abrasive Type Cut Off Saw, Model 8176-20, s/n 986A999, 15 Amp, Steel Frame Mounted
• (1998) Belt Type Tube Notcher, 28, 30, 32, 34, 36, 40 & 50mm Dia tooling, X/Y Table
• Double Wheel Polisher, Table Mounted, Misc. Wheels
• Rockwell 17” Drill Press, Model 17-600, s/n 1412041, Schwinn Tag: 776, Pedestal Type, Adjustable Table
• Seat Tube Slot Cutter, Pneumatic Clamping, Manual Feed
• (2018) Stark English Wheel, Model 61088, s/n 059, Manual Type
• Miller Tig Welder, Model Maxstar 152, s/n KJ082307, Miller Snap Start & Miller PC-300 GTAW Pulsar Control, Leads, Foot Pedal, Rolling Cart
• L-Tec Mig Welder, Model 225, s/n B90D-17246, Schwinn Tag: 2672, Leads, On Rolling Cart
• Miller Tig Welder, Model Syncrowave 350LX, s/n KK002714, Leads, Foot Pedal
• Miller Mig Welder, Model Maxstar 152, s/n KJ082308, Miller Snap Start II & Miller DC-300 GTAW Pulsar Control, Leads, Foot Pedal, On Rolling Cart
• Binks Paint Booth System, Approx. 12’ x 20’ x 8’H, 5’ x 7’ Dry Room, Recessed Lighting, Dry Filter, Del-Monox Compressed Air Purification System, Sunkiss Thermoreactor System, Badger Dry Chemical Fire Suppression System
• (Circa 2016) Cuda Rotary Parts Washer, Model H20-2530, s/n 10433680-100136, 24” Dia x 29”H Working Max Envelope, Analog Heat/Wash/Oil Skimmer Control
• Roll In Frame Drying Oven, 36” x 36” x 82”H, 6 Place Roll In Rack, Electric Type, Analog Controls, Approx. 300° Max Temp
• Frame Wash System To Wit: (3) 500 Gallon Stainless Steel Dip Tanks, Inproclean 3800 Tank Heated, (5) 120 Gallon Stainless Steel Dip Tanks, System Complete w/Wooden Cat Walks & Overhead Hoist System
• Zep Dyna 80 Agitating Lift Parts Washer, Model 917001, s/n 6055754, 80 Gallon @ 350# Max Capacity
• (1998) Kaeser Screw Type Air Compressor, Model 5M-11, s/n 01119701, 10 HP, 125 PSIG, 40 CFM, Approx. 63,858 Hours Indicated
• (1999) Deltech Refrigerated Air Line Dryer, Model 50, s/n 99KHX2975
